“Still time” – Development log #4 April 20, 2013

As promised in my previous development blog about “Still Time”, it’s time to show how levels are processed in order to achieve their polished look.

• [Step 1: tiles map] The level is assembled from a very minimalistic tiles set. The colours used in those tiles are not the ones that will actually appear on the screen. However, they indicates how they will be processed. Blue for unreachable areas, red for room backgrounds and green for lights. There are other colours as well, but they are not shown here in these screenshots.
• [Step 2: background] The background is made using a small image of bricks. Its look, however, is very artificial because they are constantly repeated with no changes.
• [Step 3: background noise] A layer of Perlin noise is added to the background. This will automatically generate the illusion of a variety among bricks.
• [Step 4: darkness] A mask of darkness is superimposed to the level. It will cover the unreachable areas.
• [Step 5: diffusive light] In order to smooth the edges of the mask, light from the red areas is diffused using Gaussian noise. With the same principle, light sources and some other objects are intentionally made brighter.
• [Step 6: dynamic light] In the last step of processing, dynamic lights are added. These Are obtained diffusing a very strong light from the green areas. Objects in front of light sources are subtracted from this mask. Finally, the dynamic light layer is blurred and added. This will produce nice occlusion effects when the character is standing in front of a window.

Step 1: tiles map	Step 2: background
Step 3: background noise	Step 4: darkness mask
Step 5: diffusive light	Step 6: dynamic light

“Still time” – Development log #3 April 16, 2013

Despite the fact that the style of “Still Time” is absolutely minimalistic, a huge effort has been put into its visual effects. In this post I will show how some frames are post-processed.

• [Step 1: dark overlay] A dark mask is superimposed to the original image. To speed up the process, there are four separate images for each edge (top, bottom, left, right). The central part of the frame is multiplied with a grey Perlin noise mask. This will result in a nice vintage effect.
• [Step 2: screen curvature] To better simulate the style of an old CRT monitor, the frame is curved. This effect is achieved with a displacement mask that is generated directly in the game.  This allows a more fine control over the amount of curvature and enables smooth animations and transitions.
• [Step 3: RGB lines] Monitors use a grid of red, green and blue lights to produce an image. In some cheap CRT models, this grid can be perceived looking closely to the image. To simulate this effect, thick RGB lines are drawn on top of the image.

In the next development blog about “Still Time” I will show how in-game frames are actually processed.
